The history of Willys Knight goes back to 1913
when J.N. Willys met up with Charles
Y. Knight whilst on a trip to England. Knight managed to convince
him that the sleeve valve engine had some very desirable attributes over
the poppet valve motor. As soon as he reached England, J.N. Willys
hired a Knight sleeve valve powered Daimler and covered 4,500 miles of
English and Scottish roads in just 15 days - a pretty good test for those
days ! In typical Willys fashion, he didn't bother negotiating
for a licence to build Knight engines for his own cars, but instead bought
the Edwards Motor Co of New York which saved him the trouble as they already
had a licence. Between 1914 and 1933 he was to sell almost half a
million of the relatively low priced but high quality sleeve valve Willys
Knights. His love affair with the sleeve valve engine also saw him
buy financial control of F.J. Stearns Co of
Cleveland, Ohio in 1925. Stearns automobiles had been using the Knight
sleeve valve engine since 1911, but were aimed at the very prestigious
and luxury end of the market. The reason why Willys Overland was
the most successful sleeve valve manufacturer lay in the enormous effort
spent on redesigning the engine for minimum manufacturing costs.
Although the sleeve valve engine had a number
of advantages such as no noisy poppet valves, no valve springs to weaken
under load or heat, a hemispherical head and an engine that could actually
show measured increases in compression and power due to carbon deposits
on the already close fitting sleeves, it was the machining costs of those
close tolerances plus the royalty fee to Knight and his partner L.B. Kilbourne
that made the poppet valve motor the sales winner.
During the Great Depression, Willys Overland declared bankruptcy
and a reorganization plan was implemented to rationalize the line up of
models. This unfortunately spelt the end of Willys Knight and the
last sleeve valve car built in America was the 1933 Model 66E Great 6,
also known as the Streamline 6 because the windshield was inclined more
than the 1932 model.
Believing that the only way to get back precious sales would be
in the small low priced area that the Overland 4 and Whippet
side valve vehicles had done so well, production was restricted solely
to the Whippet replacement - the Willys 77. True, a companion
6 cylinder model, the Willys 99 was planned, prototyped and even advertised
with a choice of poppet or sleeve valve engines, but the tooling was never
completed so it never reached production.
Willys Knight models can get a bit confusing, but the following information
extracted from the W.O.K.R. Roster (with permission) can help with identification.
The Nominal Prices column gives open car prices till 1926, then
closed cars. Serial Numbers prefixed with a C indicate Canadian origin.
Year | Model | Serial No's | Introduction
Date |
Nominal
Price(US$) |
Cyl | Bore x Stroke | B.H.P. | Wheelbase |
1914 | K-17 | 1-40 | $2750 |
|
4 x 5 1/2 | n/a | 120 | |
1914 | K-18 | 1-6 | n/a |
|
4 x 5 1/2 | n/a | n/a | |
1915 | K-19 | 1-128 | $2475 |
|
4 x 5 1/2 | 45 | 120 | |
1916 | 84 | 1-4999 | Aug 1915 | $1125 |
|
4 1/8 x 4 1/2 | 40 | 114 |
1916 | 84B | 5000-12727 | n/a |
|
4 1/8 x 4 1/2 | 40 | 114 | |
1917 | 84B | 12728-15340 | n/a |
|
4 1/8 x 4 1/2 | 40 | 114 | |
1917 | 88-4 | 1-9057 | Jul/Aug 1916 | $1650 |
|
4 1/8 x 4 1/2 | 40 | 114 |
1917 | 88-8 | 1-1419 | $1950 |
|
3 3/8 x 4 | 65 | 125 | |
1918 | 88-4 | 9058-14123 | Aug 1917 | $1525 |
|
4 1/8 x 4 1/2 | 40 | 121 |
1918 | 88-8 | 1420-2374 | Aug 1917 | $2000 |
|
3 3/8 x 4 | 65 | 125 |
1919 | 88-4 | 14124-19544 | Aug 1918 | $1725 |
|
4 1/8 x 4 1/2 | 40 | 121 |
1919 | 88-8 | 2375-2750 | Aug 1918 | n/a |
|
3 3/8 x 4 | 65 | 125 |
1920 | 20 | 1-12679 | Aug 1919 | $1750 |
|
3 5/8 x 4 1/2 | 40 | 118 |
1921 | 20 | 12680-24545 | Aug 1920 | $2195 |
|
3 5/8 x 4 1/2 | 40 | 118 |
1922 | 20-A | 24998-42229 | Jan 1922 | $1525 |
|
n/a | n/a | n/a |
1922 | 27 | 1-1073 | Fall 1922 | n/a |
|
n/a | n/a | n/a |
1923 | 64 | 1-47844 | Dec 1922 | $1235 |
|
3 5/8 x 4 1/2 | 40 | 118 |
1923 | 67 | 1-4491 | Dec 1922 | $1435 |
|
3 5/8 x 4 1/2 | 40 | 124 |
1924 | 64 | 47845-80895 | Dec 1923 | $1175 |
|
3 5/8 x 4 1/2 | 40 | 118 |
1924 | 67 | 4492-6217 | Dec 1923 | n/a |
|
3 5/8 x 4 1/2 | 40 | n/a |
1925 | 65 | 1-35798 | Jan 1925 | n/a |
|
n/a | n/a | n/a |
1925 | 67 | 6218-6310 | Jan 1925 | $1395 |
|
3 5/8 x 4 1/2 | 42 | 118 |
1925 | 66 Great Six | 1-9581 | Jan 1925 | $1845 |
|
3 1/4 x 4 3/4 | 60 | 126 |
1926 | 66 Great Six | 9582-28614 | Aug 1925 | $1750 |
|
3 1/4 x 4 3/4 | 60 | 126 |
1926 | 70 Light Six | 1-38140 | Oct 1925 | $1495 |
|
2 15/16 x 4 3/8 | 53 | 113 1/4 |
1927 | 66A Great Six | 28801-35506 | Dec 1926 | $2295 |
|
3 1/4 x 4 3/4 | 65 | 126 (or 135
from May 1927) |
1927 | 70A Special Six | 38200-69409 | Oct 1926 | $1495 |
|
2 15/16 x 4 3/8 | 53 | 113 1/4 |
1928 | 56 Standard Six | 25001-46935
C-1 to C-1333 |
Jan 1928 | $1145 |
|
2 15/16 x 3 7/8 | 45 | 109 1/2 |
1928 | 66A Great Six | 35507-40712 | Aug 1927 | $1995 |
|
3 3/8 x 4 3/4 | 70 | 126 or 135 |
1928 | 70A Special Six | 69410-84750
C-1744 to C-3331 |
Aug 1927 | $1295 |
|
2 15/16 x 4 3/8 | 53 | 113 1/4 |
1929 | 56 Standard Six | 46936-60587
C-1334 to C-1701 |
Oct 1928 | n/a |
|
2 15/16 x 3 7/8 | 45 | 109 1/2 |
1929 | 56A | C-2001 to C-2375 | n/a |
|
2 15/16 x 3 7/8 | 45 | n/a | |
1929 | 66A Great Six | 40713-42166 | Oct 1928 | $1895 |
|
3 3/8 x 4 3/4 | 70 | 126 or 135 |
1929 | 70A Special Six | C-3332 to C-3454 | n/a |
|
2 15/16 x 4 3/8 | 53 | 113 1/4 | |
1929 | 70B Light Six | 85001-110365
C-4001 to C-5261 |
Jan 1929 | $1045 |
|
2 15/16 x 4 3/8 | 53 | 112 1/2 |
1930 | 66B Great Six | 43001-48819 | Jul 1929 | $1796 |
|
3 3/8 x 4 3/4 | 87 | 120 |
1930 | 70B Light Six | 110366-121088
C-5262 to C5665 |
Oct 1929 | $1075 |
|
2 15/16 x 4 3/8 | 53 | 112 1/2 or
115 (Deluxe) |
1930 | 87 Light Six | 1001-4627
C-100 to C-256 |
Jun 1930 | n/a |
|
n/a | n/a | n/a |
1931 | 66B Great Six | 48820-50409 | Sep 1930 | n/a |
|
3 3/8 x 4 3/4 | 87 | n/a |
1931 | 66D Great Six | 1001-6620
C-100 to C-359 |
Jan 1931 | $1095 |
|
3 3/8 x 4 3/4 | 87 | 121 |
1931 | 87 Light Six | 4628-7168
C-257 to C-369 |
Sep 1930 | n/a |
|
n/a | n/a | n/a |
1931 | 95 Light Six | 1001-3798 | Jul 1931 | $896 |
|
2 15/16 x 4 3/8 | 60 | 113 |
1932 | 66D Great Six | 6701-7579
C-360 to C-480 |
Oct 1931 | $1395 |
|
3 3/8 x 4 3/4 | 87 | 121 |
1932 | 95 Light Six | 4001-4812
C-100 to C-255 |
Oct 1931 | $895 |
|
2 15/16 x 4 3/8 | 60 | 113 |
1933 | 66E Great Six | 7601-8174
C-100 to C-170 |
Jun 1932 | $1420 |
|
3 3/8 x 4 3/4 | 87 | 121 |
Interested readers should also look through the W.O.K.R. LIBRARY or W.O.K.R. STARTER INDEX for more information related to Willys Knight vehicles.
